Specification |
ITEM |
HT-ABM-0101 |
Standard |
CE Approved |
Control |
E-pneumatic |
Operating Model |
Manual, Timer,cycles |
Liquid ratio |
Automatic |
Mixing method |
static mixer |
Feed system |
1gallon tank (Other capacity can be chosen) |
Valve |
TH-700J |
Time control |
high pulse analog circuit |
Vacuum function |
Leak-proof vacuum adjusting organ |
Control way |
Foot Pedal, Finger Switch |
Dispensing time |
0.01S-9.99S |
Repeatability |
+/-0.01% |
Frequency |
600 times/minute |
Input Air pressure |
1-7 bar (100 psi) maximum (1bar =1.01972kg/cm² =14.5038psi) |
Air output |
0.1bar-0.7bar |
Input voltage |
110/220VAC |
Output voltage |
24VDC |
Power |
15W |
Temperature |
5°C to 45°C (41°F-113°F) |
Humidity |
85% RH at 30°C non-condensing |
Size |
71X42X27cm |
Weight |
37.50KG |
